Blades

Sandwich silent core blade
Features:         Silent steel core, noise reducing, Long life, free chipping, high precision.
Application:    Wet cutting granite, marble, sandstone, limestone and other stone materials.
  • Sandwich silent core blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    SSG300 12''     3.0     10 22.23
    SSG350 14''     3.2     10 25.4
    SSG400 16''     3.4     10 25.4
    SSG450 18''     3.6     10 25.4
    SSG500 20''     4.0     10 25.4
Wall saw blade
Features:         Laser welded&silver brazed style, V-shaped segment, U-Slot gullet, Holes on steel blank.
Application:    Applied for Concrete wall, Reinforced Concrete wall, brick wall.
  • Wall saw blade
  • Item diameter      Seg.     Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LWQ500 20''     4.5     10 25.4
    LWQ600 24''     4.5     10 60
    LWQ650 26''     4.5     10 60
    LWQ700 28''     4.5     10 60
    LWQ750 30''     4.5     10 60
    LWQ800 32''     4.5     10 60
    LWQ900 36''     4.5     10 60
    LWQ1000 40''     4.5     10 60
    LWQ1100 44''     4.5     10 60
    LWQ1200 48''     4.5     10 60
    Various teeth,slots,arbor,bonds available.
Laser welded tuck point
Features:         Premium diamond and high diamond concentration provide fast cutting and longer life.Expansion jionts between bricks. Making grooves on the surface of construction materials.
Application:    Professional cutting out mortar, stone and concrete removal.
  • Laser welded tuck point
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LTK105 4''     6.35/9.5     7/10 22.23
    LTK115 4.5''     6.35/9.5     7/10 22.23
    LTK125 5''     6.35/9.5     7/10 22.23
    LTK180 7''     6.35/9.5     7/10 22.23
Laser welded blade
Features:         The cutting depth is up to 260mm.
Application:    Special bond for a wide range of material: reinforced concrete, precast concrete, Brick
  • Laser welded blade
  • Item Diameter      Seg.    Seg.  Seg.
     No. inch Thickness(mm) height(mm)   No
    LRJ350 14''     4.2     8/10   22
    The Guide roller is also available.
Laser welded blade
Features:         Unique design for longer cutting life and fastest cut speed.
Application:    Efficient cutting for a diverse range of materials: Concrete block, paver, brick, reinforced concrete
  • Laser welded blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LMJ300 12''     3.0     10 22.23
    LMJ350 14''     3.2     10 25.4
    LMJ400 16''     3.4     10 25.4
    LMJ450 18''     3.6     10 25.4
    LMJ500 20''     4.0     10 25.4
Laser welded blade
Features:         High diamond concentration and soft bond blades professionally process hard aggragates:
Application:    hard brick, Steel bar reinforced concrete, hard stone, refractory brick and other high density materials.Other specifications are available as your request.
  • Laser welded blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LHJ300 12''     3.0     10 22.23
    LHJ350 14''     3.2     10 25.4
    LHJ400 16''     3.4     10 25.4
    LHJ450 18''     3.6     10 25.4
    LHJ500 20''     4.0     10 25.4
    LHJ550 22''     4.0     10 25.4
    LHJ600 24''     4.2     10 25.4
Laser welded blade
Features:         Mature bond; no damage to notch edges during cutting;high speed and long service life.
Application:    For professional cutting cured concrete,hollow core concrete, reinforced concrete with heavily steel bar inside.
  • Laser welded blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LCJ300 12''     3.0     7/10/12 22.23
    LCJ350 14''     3.2     7/10/12 25.4
    LCJ400 16''     3.4     7/10/12 25.4
    LCJ450 18''     3.6     7/10/12 25.4
    LCJ500 20''     4.0     7/10/12 25.4
    LCJ550 22''     4.0     7/10/12 25.4
    LCJ600 24''     4.2     7/10/12

    25.4

    Dia12"-36" laser welded style blades available.

    Various teeth,slots,arbor,bonds available.

Laser welded blade
Features:         Wide U-slot, key-slot or slant teeth supply aggressive cutting speed and better service life.
Application:    Ideal bond for cutting abrasive materials: green concrete, asphalt and asphalt over concrete roadways.
  • Laser welded blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    LAJ300 12''     3.0     10 22.23
    LAJ350 14''     3.2     10 25.4
    LAJ400 16''     3.4     10 25.4
    LAJ450 18''     3.6     10 25.4
    LAJ500 20''     4.0     10 25.4
    LAJ550 22''     4.0     10 25.4
    LAJ600 24''     4.2     10 25.4
Segmented vacuum brazed blade
Features:         Extra-fast cutting speed, special designed and advanced vacuum brazing technology.
Application:    Professionally used for steel, cast iron, natrual stone, ductile iron pipe, porcelain,wood, rebar concrete, PVC, other building materials.
  • Segmented vacuum brazed blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    VAS105  4''     2.2     6/7.5  20
    VAS115 4.5''     2.4     6/7.5  22.23
    VAS125  5''     2.4     6/7.5  22.23
    VAS180  7''     2.4     6/7.5  22.23
    VAS230  9''     2.8     6/7.5  22.23
Sintered Blades
Features:         High diamond concentration and soft bond blades professionally process hard aggragates
Application:    Hard brick, Steel bar reinforced concrete, hard stone,refractory brick and other high density materials.
  • Sintered Blades
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    SHJ180  7''     2.2     10 22.23
    SHJ230  9''     2.4     10 22.23
    SHJ300 12''     3.0     10/12 25.4
    SHJ350 14''     3.2     10/12 25.4
    SHJ400 16''     3.4     10/12 25.4

Protection teeth turbo blade
Features:         Fast and smooth cutting, Long life, free chipping, high precision.
Application:    Wet cutting granite, marble, sandstone, limestone and other stone materials.
  • Protection teeth turbo blade
  • Item diameter      Seg.     Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    SPT105 4''     1.8     8 22.23
    SPT115 4.5''     1.9     8 22.23
    SPT125 5''     2.0     8 22.23
    SPT150 6''     2.0     8 22.23
    SPT180 7''     2.2     8 22.23
    SPT200 8''     2.4     8 22.23
    SPT230 9''     2.4     8 22.23
    SPT250 10''     2.6     8 22.23
    SPT300 12''     2.8    10 25.4
    SPT350 14''     3.0    10 25.4
    Various teeth, slots,arbor,bonds available.
Granite blade
Features:         Fast and smooth cutting, Long life, free chipping, high precision.
Application:    Wet cutting granite, marble, sandstone, limestone and other stone materials.
  • Granite blade
  • Item Diameter       Seg.     Seg.    Arbor
     No.  Inch Thickness(mm) height(mm)    (mm)
    SGH300   12''      3.0    10/12    22.23
    SGH350   14''      3.2    10/12/15    25.4
    SGH400   16''      3.4    10/12/15    25.4
    SGH450   18''      3.6    10/12/15    25.4
    SGH500   20''      4.0    10/12/15    25.4
    SGH600   24''      4.2    10/12/15    60
    SGH650   26''      4.5    10/12/15    60
    SGH700   28''      4.5    10/12/15    60
    SGH750   30''      4.5    10/12/15    60
    SGH800   32''      4.5    10/12/15    60
    SGH900   36''      4.5    10/12/15    60
    SGH1000   40''      4.5    10/12/15    60
    SGH1100   44''      4.5    10/12/15    60
    SGH1200   48''      4.5    10/12/15    60
    Various teeth, slots,aror,bonds available.

Silver brazed saw blade
Features:         Mature bond,No damage to notch edges during cutting. high speed and long service life.
Application:    For professional cutting cured concrete with various aggragates and heavily steel bar inside.
  • Silver brazed saw blade
  • Item  Diameter      Seg.    Seg.  Arbor
     No inch Thickness(mm) Height(mm)   (mm)
    SCH300 12''     3.0      10    22.23
    SCH350 14''     3.2      10    25.4
    SCH400 16''     3.4      10    25.4
    SCH450 18''     3.6      10    25.4
    SCH500 20''     3.8      10    25.4
    SCH550 22''     4.0      10    25.4
    SCH600 24''     4.2      10    25.4
    SCH700 28''     5.0      10    25.4
    SCH800 32''     6.0      10    25.4
    SCH900 36''     6.5      10     60
    SCH1000 40''     7.0      10     60
    SCH1100 44''     7.0      10     60
    SCH1200 48''     7.0      10     60
    Various teeth,slots,arbor,bonds available.
Sintered tuck point
Features:         Premium Diamond and High diamond concentration provide fast cutting and longer life.Expansion jionts between bricks. Making grooves on the surface of construction materials.
Application:    Professional cutting out Mortar, stone and concrete removal.
  • Sintered tuck point
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    STP105 4''      6.35     7/10 22.23
    STP115 4.5''      6.35     7/10 22.23
    STP125 5''      6.35     7/10 22.23
    STP180 7''      6.35     7/10 22.23
Sintered concave blade
Features:         High precision, free chipping,
Application:    Special designed for curves and circles cutting on different porcelain, ceramic tiles and stone.
  • Sintered concave blade
  • Item Diameter      Seg.    Seg.  Arbor
     No. inch Thickness(mm) height(mm)  (mm)
    SCS105 4''     2.4     8 22.23
    SCS115 4.5''     2.4     8 22.23
    SCS125 5''     2.4     8 22.23
    SCS150 6''     2.6     8 22.23
    SCS180 7''     3.0     8 22.23
